1.Quad-core 2.0GHz Cortex-A55 high-performance processor
2.15.6” FHD touch screen + 10.1” HD optional
3.Anti-interference touch screen
4.Robust alloy base with topline hole
Product Features:
1.Quad-core 2.0GHz Cortex-A55 high-performance processor
2.15.6” FHD touch screen + 10.1” HD optional
3.Anti-interference touch screen
4.Robust alloy base with topline hole
Product parameters:
|
Performance Parameters |
CPU |
RK3568 Quad-core Cortex-A55 2.0GHz |
|
OS |
Android 11.0 |
|
|
Memory |
2GB RAM+16GB ROM 4GB RAM+64GB ROM (optional) |
|
|
Physical Parameters |
Main Display |
15.6”FHD Capacitive Multi-Touch Screen, 1920*1080） |
|
Customer Display（optional） |
10.1”HD 1024×600 |
|
|
USB |
2 x USB3.0 + 3 x USB2.0 |
|
|
Serial Port |
1 x RJ11 |
|
|
Cash Drawer Interface |
1 x RJ12 |
|
|
Ethernet Interface |
1 x RJ45 |
|
|
Audio Interface |
1 x 3.5mm Headphone jack |
|
|
Power |
1 x φ5.5mm DC Jack |
|
|
Key |
Power key |
|
|
Notification |
Tone, LED |
|
|
Audio |
1 x Speaker |
|
|
Dimensions |
379mm×179mm×313mm |
|
|
Wireless Data Communication |
Ethernet |
TCP/IP 100M/1000M |
|
Wi-Fi |
IEEE 802.11 b/g/n，2.4GHz |
|
|
Bluetooth |
Bluetooth BT4.2 + BLE |
|
|
Environment Parameters |
Working Temperature |
0℃ ～+40℃ |
|
Storage Temperature |
-20℃ ~ +60℃ |
|
|
Humidity |
5% ~ 95%RH（No condensation） |
|
|
ESD |
±8 kV air discharge，±4 kV direct discharge |
|
|
Accessories |
Standard |
Power Adapter×1 |
|
Optional |
Face Recognition Camera MSR NFC |
