● High Integration and Small Size ● Octa-core 2.0GHz ARM Cortex-A73 High-performance Processor ● 10.1”Main Display and 4”Guest Display Dual Screen ● Rich Interfaces that can Expand Various Commercial Peripherals ● Built in 80mm High-speed Printer with Automatic Cutting ● Support QR Code and Membership Card Payment
Read More
● Your fashion partner to grow business. ● Quad-core 2.0GHz ARM Cortex-A55 high-performance processor ● Thin and stylish aluminum body ● Cables concealed ● Modular design, efficient user service ● Manually detachable 2nd display and support scanning module
Read More
i2 is a new generation of high performance, multifunctional PDA launched by iMACHINE, with fully performance and experience feeling. The screen is 5.5inch HD, which is portable and comfortable to hold. It has more stable connection, richer match, super industrial protection performance, fully meet the needs of industrial applications. i2 is perfectly suit to many scenarios, such as logistics, express, warehouse inventory, manufacturing, retail e-commerce, public utilities, asset management etc. The goal is to improve the operation and management level with efficiently data collection.
Read More
From July 27th to 29th, Retail NOW2025 focused on global retail innovation, the fair was held as scheduled in Las Vegas, USA! iMACHINE showcased a var
● High Integration and Small Size
● Octa-core 2.0GHz ARM Cortex-A73 High-performance Processor
● 10.1”Main Display and 4”Guest Display Dual Screen
● Rich Interfaces that can Expand Various Commercial Peripherals
● Built in 80mm High-speed Printer with Automatic Cutting
● Support QR Code and Membership Card Payment
● High Integration and Small Size
● Octa-core 2.0GHz ARM Cortex-A73 High-performance Processor
● 10.1”Main Display and 4”Guest Display Dual Screen
● Rich Interfaces that can Expand Various Commercial Peripherals
● Built in 80mm High-speed Printer with Automatic Cutting
● Support QR Code and Membership Card Payment
|
Performance Characteristics |
CPU |
Octa-core 2.0GHz ARM Cortex-A73，12nm |
|
OS |
Android 14 |
|
|
Memory |
3GB RAM+64GB ROM 4GB RAM+64GB ROM (optional) |
|
|
SIM Card Slot |
2 x Nano SIM Cards |
|
|
PSAM Card Slot |
2 x PSAM Cards |
|
|
Expansion Storage |
1 x Micro SD Card（up to 128GB） |
|
|
Physical Characteristics |
Main Display |
10.1”HD 1280×800 Capacitive Multi-Touch Screen |
|
2nd Display |
4”800×480 |
|
|
Built-in Printer |
Printing method: Thermal receipt Printing Speed：170mm/s Printing Resolution：203dpi Paper Width：80mm Paper Roll Diameter：80mm Auto Cutter：Support Support virtual Bluetooth printing |
|
|
USB |
4 x USB Type-A+1 x USB Type-C |
|
|
COM |
1 x RJ11 |
|
|
Cash Drawer Interface |
1 x RJ12（Drawer Port 24V） |
|
|
Ethernet Interface |
1 x RJ45 |
|
|
Power Interface |
1 x φ5.5mm DC Jack |
|
|
Key |
1×Power key , 1×Volume(+/-) key, 1×Function key |
|
|
Notification |
Tone |
|
|
Audio |
Speaker (3W), Microphone |
|
|
Dimensions |
312 x 265 x 110mm |
|
|
Data Capture |
Camera |
5M QR code scanning camera Support fill light prompt |
|
NFC |
Support ISO15693, ISO14443A/B, Mifare card, Felica card |
|
|
Network Connection |
Wireless WAN |
TDD-LTE(B34/B38/B39/B40/B41) FDD-LTE(B1/B3/B5/B7/B8/B20) TD-SCDMA(B34/B39) WCDMA(B1/B2/B5/B8) GSM/EDGE/GPRS(850/900/1800/1900) |
|
Ethernet |
TCP/IP 100M |
|
|
Wireless LAN |
2.4&5GHz dual-band Wi-Fi IEEE 802.11 ac/a/b/g/n |
|
|
Wireless PAN |
BT5.0 + BR/EDR + BLE |
|
|
User Environment |
Operating Temp. |
0℃ ～+40℃ |
|
Storage Temp. |
-20℃ ~ +60℃ |
|
|
Humidity |
5% ~ 95%RH（No condensation） |
|
|
Accessories |
Standard |
Power Adapter (24V)×1 Thermal printing paper x 1 |
A1 Smart Desktop Terminal (Android)
1.All in one POS，new retail experience 2.Quad-core 2.0GHz Cortex-A55 high-performance processor 3.14" main display and 14" customer display 4.Anti-interference touch screen 5.Multi peripheral expansion interface
A2 Windows Desktop POS Terminal
1.Digitalized Retail New Experience 2.High Performance, Low Power Consumption Processors 3.Full Aluminum Alloy Build 4.15.6”Ultra-Slim Framed FHD Display 5.Foldable Design 6.Comprehensive Interfaces
A1 PLUS Smart Desktop Terminal
1.All in one POS，new retail experience 2.High-performance intel CPU, low power processor 3.Multi configuration options 4.14" main display and 14" customer display 5.Anti-interference touch screen 6.Multi peripheral expansion interface 5. CCC, FCC, CE Certification
P1 Windows Desktop POS Terminal
1.High performance, low power processor 2.15.6” FHD touch screen + 10.1” HD optional 3.Robust alloy base with topline hole 4.Anti-interference touch screen
P1 Android Desktop POS Terminal
1.Quad-core 2.0GHz Cortex-A55 high-performance processor 2.15.6” FHD touch screen + 10.1” HD optional 3.Anti-interference touch screen 4.Robust alloy base with topline hole
P3 Smart Desktop POS Terminal（Android）
● Your fashion partner to grow business. ● Quad-core 2.0GHz ARM Cortex-A55 high-performance processor ● Thin and stylish aluminum body ● Cables concealed ● Modular design, efficient user service ● Manually detachable 2nd display and support scanning module
A2 Android Desktop POS Terminal
● Digitalized Retail New Experience ● Quad-core 2.0GHz ARM Cortex-A55 High-performance Processor ● Full Aluminum Alloy Build ● 15.6”Ultra-Slim Framed FHD Display ● Foldable Design ● Plenty of Peripheral Support and Rich I/O Interface
P2 Smart Desktop Terminal （Windows）
●Stable and Durable Perfect Partner ●Compatible with More High-performance Processors ●Industrial and Stylish Exterior Design ●Plenty of Peripheral Support and Rich I/O Interface ●Wall Mounted Design that Meets VESA Standards ●Modular Design, Efficient User Service and Extendable 2nd Display
