POS Terminal TK01
CPU
Quad-core 2.0GHz
OS
Android 8.1
RAM
2GB
ROM
16GB
Camera
Front Camera 5MP FF, Rear camera 13MP AF , High brightness LED flash
Display size/type
3.5 inch, IPS highlight screen
Resolution
640*960
Touch Screen
5-point capacitive touch screen
Size
185*70*32mm
Weight(with battery)
300g
Battery capacity
5200mAh
Charging
PE fast charging, full charged time<4 hours
Bluetooth
BT4.1 BLE
Wi-Fi
IEEE 802.11 a/b/g/n 2.4G 5Gdual frequency
WWLAN
FDD-LTE B1/B3/B7
TDD-LTE B38/B39/B40/B41
TDSCDMA B34/B39
WCDMA B1/B2/B5/B8
GSM B2/B3/B5/B8
CDMA1x/CDMA2000 BC0
GPS
GPS+BD+GLONASS
Audio
Front dual stereo speakers, Volume 90db±3db(test distance 10cm)
Sensor
Gsensor, Ambient light sensor, Proximity Sensor, COMPASS
Expansion
Micro SD(TF) card slot up to 128GB
Interface
USB-Type C, support fast charging, OTG
charging and bottom USB connector; support cradle extension
Keypad
35 buttons(2 volume buttons, 1 power button, 2 function buttons)
Notification
Sound, Vbration, LED prompt
Operating temperature
-20℃ to +55℃
Storage temperature
-30℃ to +70℃
Working Humidity
5% to 95%
IP Class
IP65
Drop test
6 sides can withstand the impact of 1.5 meters drop to the concrete floor
ESD
±15kV Air Discharge, ±8kV Contact Discharge
Certificate
CCC、CE
RFID(HF)
ISO14443A/B, ISO15693, NFC reading distance: 0~5cm
Scan Engine
CM60
Barcode scanning Support code system
Support code system: EAN13, EAN8, UPCA, UPCE, Code 128, Code 39, Codabar, UCC/EAN128, RSS,ITF, ITF14, ITF6, ISSN, ISBN, Standard 25, Matrix 25,Industrial 25,Plessey, MSI Plessey, Code 11, Code 93, PDF417, QR Code, DataMatrix, AZTEC, Hanxin Code, Maxicode, Micro QR,Micro PDF417, Composite
