i1 PLUS Smart Handheld Data Terminal

iMACHINE i1 PLUS is a new generation of high-end flagship intelligent handheld intelligent data terminal launched by iMACHINE. After the careful research and developing of professional team, the ultimate high performance and practicality are perfectly integrated. The thin and light body is equipped with a 6-inch FHD+ and 3D micro-curved full HD screen, it leads the trend of the high-end mobile data terminal with high-performance configuration that pursues excellent productivity and leads the industry in all orientations.

iMACHINE i1 PLUS is perfectly suitable for application scenarios in many industries such as logistics express, warehousing inventory, manufacturing, retail e-commerce, public utilities, asset management, etc. Helping customers efficiently collect data to improve operation and management level.

  • Product Features
  • Product parameters
  • Product Details

Product Features:

Powerful performance for smooth operation

The Octa-Core 2.0GHz high-performance processor brings an extraordinary experience, and with large running memory and Android 11 operating system, it achieves that multiple programs can run quickly and stably at the same time, bringing an efficient business experience.

4G full network + high-speed Wi-Fi, data transmission unimpeded

Dual SIM dual standby 4G full Netcom, whether you are indoors or outdoors, you can stay connected anytime, anywhere;

2.4G/5G dual frequency band professional Wi-Fi, strong anti interference ability, faster transmission speed, more stable back connection, seamless roaming switching;

The triple positioning of GPS+ Beidou +Glonass has higher accuracy and meets the precise positioning needs of the express delivery scene.

With professional scanning engine, Fast code sweeping

Equipped with a variety of industry-leading scanning head engines, whether it is dirty code, old code, distorted code, DPM code, screen display code, can be easily read;

Wide scanning range and scanning distance make the scanning code work more easily, without deliberate alignment can be accurately read.

QC3.0 ultra-fast flash charge, no worries about battery endurance

Support QC3.0 standard 18W fast charge, full of 50% power in half an hour, you can quickly complete the charge during the rest interval;

The battery adopts a one-button ejection battery buckle design, and the battery is replaced as fast as lightning;

Built-in SuperCap power swap without shutdown solution, seamless switching between power replacement and maintaining efficiency.

6inches 1080P high-definition screen, industrial-grade performance and consumer-grade experience

6inches FHD + HD flagship screen, 3D micro curved surface technology makes the grip more comfortable, the field of vision wider, and the visual feeling more smooth;

In all harsh scenarios such as gloves, wet hands, cold, rainy days, etc., it can also ensure industrial-grade stable and accurate input capabilities

2W super linear speakers, always enjoy the auditory feast

2W superlinear speaker is adopted, with large loudness, wide range, and three-dimensional and grand sound field;

BOX sound chamber design, high volume without breaking the sound, gives you a clear and transparent high pitched and full and shocking bass experience.

PDAF Phase Detection Auto Focus technology, high-definition "dual camera" is clearer

Front 5Megapixel fixed focus camera + Rear 16Megapixel auto focus camera to meet the needs of taking pictures in different scenarios;

By using PDAF (Phase Detection Auto Focus) technology, it can focus faster, better image quality, fast and clear image acquisition.

Anti-drop and more durable, no fear of harsh working environment

High-standard industrial-grade protection design, no fear of violent challenges;

Wide temperature design, it can be used normally in cold storage, steel mill, desert or tropical rain forest.


Product Parameters:

System Parameters CPU Octa-core 2.0GHz
OS Android 11.0
Memory 4GB RAM+64GB ROM
SIM Card Slot 2 x Nano SIM Cards
Storage Expansion 1 x Micro SD Card,(SDHC、SDXC supported, up to 512GB)
Physical Parameter Display 6”FHD+WVGA IPS 1080*2160p, Capacitive Multi-Touch, Glove mode support
Battery Removable Lithium Battery, 3.85V/5000mAh
Backup battery Support hot swap the battery, device keep working(optional)
Dimensions(L*W*H) 162.8mm×77mm×12.9mm
Weight 260 g(with battery)
Ports 1×Waterproof Type C ( support USB 2.0, OTG, Fast charging)
Expansion Ports Back POGO PIN:USB 2.0,Serial port ,5V/3A
Bottom POGO PIN:USB 2.0,5V/3A
Buttons 1×Power(lock screen) button
1×Volume(+/-) button
1×Custom button
2×Scan buttons
Prompts Vibration reminder,Multi-Color LED reminder,audio reminder
Audio Ultra Linear Speaker(2W)、Receiver, Dual Microphones (noise reduction)
Sensor G-Sensor, Light Sensor, Proximity Sensor, E-compass, Gyroscope
Environment Parameters Operating Temperature -20℃ ~+60℃
Storage temperature -40℃ ~ +70℃
Humidity 5% ~ 95%RH(No condensation)
Protection IP68
Drop Specification 1.5m
Roller Drop 1000 times of roller drops from a height of 0.5 meters (equivalent to 2000 impacts)
Electrostatic Protection ±15 kV air discharge, ±8 kV direct discharge
Data collection 2D Scanning (optional ) 1D and 2D Barcodes Reader
Image Capture Rear camera: 16 Megapixel, Support flash and auto focus
Front camera : 5 Megapixel, fixed focus
GPS GPS/Glonass/Beidou, support AGPS
NFC (optional) Supports ISO15693, ISO14443A/B, MIFARE, Felica interface protocol
Support card reading, point - to - point, card simulation
Fingerprint (optional) Support fingerprint recognition
Wireless Data Communication WWAN 4G full network,Eurasian and American Versions
Wi-Fi IEEE 802.11 ac/a/b/g/n/ax ready/d/e/h/i/j/k/r/v/w
2.4G/5G dual bands Wi-Fi, support 802.11r fast roaming
Bluetooth BT5.1 + BR/EDR + BLE
Accessories Standard Power Adaptor×1, USB Cable×1, Battery×1
Optional Hand strap, Base charger, Four-slot battery charger, Trigger handle, Fast charging adapter, RFID-UHF Handle, wireless charging back clip, optical fingerprint module, Type C USB earphone.
-
