i1H Medical Mobile Data Terminal

iMACHINE i1H is a new generation of high performance, ultra-thin intelligent medical data terminal, launched by iMACHINE based on its in-depth understanding of the medical industry with fashionable appearance and novel color matching. The screen is 5.5inch full HD screen, which is portable and comfortable to hold. Using antibacterial and sterilizable materials can effectively prevent the spread of bacterial infection, super industrial protection performance and industrial adaptation for the strong protection of medical health.

  • Product Features
  • Product parameters
  • Product Details

Product Features:

Antibacterial and sterilizable materials

The shell is made of antibacterial material in accordance with JISZ2801 standard, which can withstand routine disinfection with commonly used disinfectants and alcohol-resistant wiping, effectively preventing the spread of bacterial infection by wiping the equipment.

Strong performance, let the operation flow

Eight-core 2.0ghz high performance chip brings extraordinary experience, with large running memory and Android 11 operating system, realize the rapid and stable running of multiple programs at the same time, bringing efficient business experience.

4G full network + high-speed Wi-Fi, unimpeded data transmission

Dual SIM dual standby 4G full network, easy to cope with a variety of medical environment, no matter where you are indoors or outdoors, you can always have connected;

Professional 2.4G/5G dual band Wi-Fi, strong anti-interference ability, faster transmission speed, more stable back connection, seamless roaming

With professional scan engine enable fast code scan

Equipped with industry-leading scan engines, whether it is dirty code, old code, distorted code, DPM code, screen display code, it can read easily;

Wide scan range and distance makes the work more easily which enable accurate reading without deliberate alignment.

5000mAh large battery and 18W fast charge, no battery anxiety anymore

Equipped with 5000mAh large battery meet frequently operations. At the same time, the back shell adopts a one-button ejection battery buckle design, one can change the power so fast;

With built-in Super Cap power changing without shutdown, maintains efficiency during replacing power;

With 18W quick charging scheme, there is no fear of power anxiety any more.

Ultra-high screen ratio, better visual interaction

5.5-inch narrow frame screen, broad view, it is clearly visible even in outdoor strong light which make outdoor work more convenient;

With multi- touch screen reaction, no worry about gloves, wet hands, passive capacitive pen. It can be used as usual.

More durable Resistant, more ease in harsh working environment

Through its own hardware and structure optimization, the design is more ergonomic products, and the grip is lighter and more comfortable to hold;

The fuselage adopts industrial-grade integrated molding process, with three protection grades up to IP68, which can withstand the drop of 1.5 m cement floor at any Angle, meeting the demand of harsh environment.

Performance Parameters



CPU

Octa-core 2.0GHz

OS

Android 11.0

Memory

4GB RAM+64GB ROM

SIM Card Slot

2 x Nano SIM cards

Expansion Storage

1 x Micro SD Card(SDHC、SDXC supported,up to 512GB)

Physical Parameters

Display

5.5HD, Industrial grade IPS, 720×1440

Capacitive multi-touch touch, support glove mode

Battery

Removable Lithium Battery, 3.85V/5000mAh

Backup battery

Support hot swap the battery, the device keeps working(optional)

Dimensions

(L*W*H)

156.2mm x 74.8mmx 14.3mm

Weight

250 g (with battery)

Ports

1×Waterproof Type C ( support USB 2.0, OTG, Fast charging)

Expansion Ports

Back POGO PIN: Trigger handle

Bottom POGO PIN: USB 2.0, 5V/3A

Buttons

1×Power(lock screen) button

1×Volume(+/-) button

1×Custom button

2×Scan buttons

Prompts

Vibration reminder, Multi-Color LED reminder, audio reminder

Audio

Built-in speaker (1.5W), receiver, dual microphone (noise reduction)

Sensor

G-Sensor, Light Sensor ,Proximity Sensor, Gyroscope, E-compass

Environment Parameter

Working Temperature

-20℃ ~+60℃

Storage temperature

-40℃ ~ +70℃

Humidity

5%-95% RH (No condensation)

Protection

IP68

Drop Specification

1.5m

Roller Drop

1000 times of roller drops from a height of 0.5 meters (equivalent to 2000 impacts)

Electrostatic Protection

±15 kV air discharge, ±8 kV direct discharge

Data collection

2D Scanning (optional)

1D and 2D Barcodes Reader

Image Capture

Rear camera: 13 Megapixels, flash support, auto focus

Front camera (optional): 5 Megapixels, Fixed Focus

GPS

GPS/Glonass/Beidou, support AGPS

NFC

(optional)

Support ISO15693, ISO14443A/B, Mifare card, Felica card

Support card reader, Point-to-point, Card simulation

Fingerprint (optional)

Support fingerprint unlock

Wireless Data Communication Function

WWAN

4G full network,Eurasian and American Versions

Wi-Fi

IEEE 802.11 ac/a/b/g/n/ax ready/d/e/h/i/j/k/r/v/w

2.4G/5G dual-band Wi-Fi, support 802.11r fast roaming

Bluetooth

BT 5.0 + BR/EDR + BLE

Accessories

Standard

Power Adaptor×1, USB Cable×1, Battery×1

Optional

Hand strap, Base charger, Four-slot battery charger, Trigger handle, Fast charging adapter

-
